u-he Colour Copy

a bucketful of delay

u-he Colour Copy offers up a bucketful of delay.  It’s a virtual analog effect inspired by classic bucket-brigade delays (BBD), but extended with modern features. We called our new baby “Colour Copy” because it can deliver the kind of coloration that people still love in classic BBD units, but with a wider variety of colors. Colour Copy started life as the little delay unit called “Lyrebird” we built into Repro-1, but the sound was too good not to be developed further and become an FX plug-in.

Colour Copy Highlights

• BBD-style analog delay, for the smoothest possible pitch effects
• unique colour morphing, with saturation for non-linear effects such as distortion / resonance
• 1ms to 1s or host-synched time base, scaled via rate control from 25% to 400%
• dynamic ducking via envelope follower
• LFO (with dynamic frequency and depth) can modulate rate, tap position or amplitude.
• MIDI note tracking and Freeze button (infinite loop) for wildest experimental effects
• powerful preset browser with tag and/or text search functions
• independent input and feedback routing options allow all possible stereo or mono combinations
• 100 factory presets, NKS-compatible
• UI instantly resizable from 70% to 200%
• custom remote control via MIDI CC, 14-bit resolution option

Features

Colours

During development we soon realized that we could capture the essence of the entire range of classic bucket brigade delays – from the low-range rumbling, slowly evolving delays to the highly resonant, screaming characters. A single knob lets you continuously blend between the five finely-tuned “colour” macros. The differences may be subtle, but each one is rich in detail. In addition to obvious differences in frequency bandwidth, each comes with its own noise and dynamic characteristics, frequency loss over time, and several other qualities. The Saturation knob controls how prominent or subtle those characteristics should be, in case you want to dial back the colouration to better fit in the mix. Finally, a Brightness knob lets you adjust the bandwidth.

Flexibility

Colour Copy is capable of a huge variety of different delay-based effects. With delay times ranging from under a millisecond to several seconds, you can create anything from comb-filter and flange/chorus effects to regular ping-pong delays and longer “looper” effects. The routing options let you mix or swap the input and feedback signals independently or even invert the feedback phase for various phase cancellation effects when delay times are set very short. Additionally, unlike hardware BBD units, Colour Copy’s left and right output “taps” can be placed anywhere along the delay lines. This feature lets you move echos independently “forward in time” for e.g. ping-pong or “rushing” delays as well as various stereo chorus or flanger effects. You never knew you’d want three different ways to create a ping-pong effect!

Animation

Colour Copy comes with a stereo LFO that can be used to modulate either the delay rate, the tap positions or the delay amplitude. With a range of 0.05Hz to 20Hz (as times: 20s to 50ms) the LFO can create chorus, vibrato and tremolo effects. Crank up the modulation depth for deep pitch-shifting. An envelope follow signal derived from the input signal can be used to modulate the LFO frequency and depth, adding realtime dynamics to the effects.

Modulation section

Colour Copy comes with the obligatory ducking compressor, but with a unique twist: You can select whether to duck the entire delay output or just the feedback signal. This latter option leaves the very first delay unaffected, preserving the overall stereo “space” while preventing the sonic mayhem that high regeneration often causes.

Performance Control

Some people like to perform on their BBD hardware, pitching the regeneration up and down by twisting the rate knob. We took Colour Copy a step further in this direction by adding a pair of creative features: Firstly, a freeze button that loops the contents of the delay buffer for as long as you like. Secondly, MIDI key control so that you can play Colour Copy like a mono synth – each octave up doubles the delay rate.
